Output power max

20kW

30kW

30kW

60kW

Pulse voltage range

200~1000V

200~1000V

200~1000V

200~1000V

Pulse peak current

400A

1000A

1500A

2000A

Pulse frequency range

100~2500Hz

20~1000Hz

20~1000Hz

20~1000Hz

Pulse width range

10~500uS

10~300uS

10~300uS

10~300uS

DC voltage range

200~750V

200~750V

200~750V

200~750V

DC current max

0.5—20A

0.5—20A

0.5—20A

0.5—20A

Module synchronization

                         optical fiber

      optical fiber

      optical fiber

      optical fiber

Waveform interface

                  BNC voltage/current

BNC voltage/current

BNC voltage/current

BNC voltage/current

Communication

Interface

                     RS485

                       RS485

RS485/CAN/Profibus/Profinet/TCPIP/EarthCAT，customized

RS485/CAN/Profibus/Profinet/TCPIP/EarthCAT，customized

Feature

Changeable waveform,suitable for small targets

Cost-effective, customizable bipolar waveform output

Pulse with positive pressure, fixed amplitude output

High voltage and high current, regular pulse current waveform

Application

or various high-quality functional coatings,widely used in tools,molds, medical devices,automotive components and general industries
